Argocd

Argo CD is a declarative, GitOps continuous delivery tool for Kubernetes.

Why Argo CD?

Application definitions, configurations, and environments should be declarative and version controlled. Application deployment and lifecycle management should be automated, auditable, and easy to understand.

How it works?

Argo CD follows the GitOps pattern of using Git repositories as the source of truth for defining the desired application state. Kubernetes manifests can be specified in several ways:

• kustomize applications
• helm charts
• jsonnet files
• Plain directory of YAML/json manifests
• Any custom config management tool configured as a config management plugin

Argo CD automates the deployment of the desired application states in the specified target environments. Application deployments can track updates to branches, tags, or pinned to a specific version of manifests at a Git commit. See tracking strategies for additional details about the different tracking strategies available.

Provision

bash docker/docker.sh
bash minikube/minikube.sh
bash argocd/argocd.shCopy to clipboardErrorCopied

vagrant up --provision-with basetools,docsify,docker,minikube,argocdCopy to clipboardErrorCopied

docker compose exec hashiqube /bin/bash
bash hashiqube/basetools.sh
bash docker/docker.sh
bash docsify/docsify.sh
bash minikube/minikube.sh
bash argocd/argocd.shCopy to clipboardErrorCopied

Links

• https://argo-cd.readthedocs.io/en/stable/operator-manual/installation/
• https://devopscube.com/setup-argo-cd-using-helm/

Provisioner

argocd.sh

#!/bin/bash
# https://argo-cd.readthedocs.io/en/stable/operator-manual/installation/
# https://devopscube.com/setup-argo-cd-using-helm/

arch=$(lscpu | grep "Architecture" | awk '{print $NF}')
if [[ $arch == x86_64* ]]; then
  ARCH="amd64"
elif  [[ $arch == aarch64 ]]; then
  ARCH="arm64"
fi
echo -e '\e[38;5;198m'"CPU is $ARCH"

echo -e '\e[38;5;198m'"++++ "
echo -e '\e[38;5;198m'"++++ Ensure Docker Daemon is running (Dependency)"
echo -e '\e[38;5;198m'"++++ "
if pgrep -x "dockerd" >/dev/null
then
  echo -e '\e[38;5;198m'"++++ Docker is running"
else
  echo -e '\e[38;5;198m'"++++ Ensure Docker is running.."
  sudo bash /vagrant/docker/docker.sh
fi

echo -e '\e[38;5;198m'"++++ "
echo -e '\e[38;5;198m'"++++ Ensure Minikube is running (Dependency)"
echo -e '\e[38;5;198m'"++++ "
if pgrep -x "minikube" >/dev/null
then
  echo "Minikube is running"
else
  echo -e '\e[38;5;198m'"Minikube is not running, launching"
  sudo bash /vagrant/minikube/minikube.sh
fi

echo -e '\e[38;5;198m'"++++ "
echo -e '\e[38;5;198m'"++++ Create Argocd Namespace"
echo -e '\e[38;5;198m'"++++ "
sudo --preserve-env=PATH -u vagrant kubectl create namespace argocd

echo -e '\e[38;5;198m'"++++ "
echo -e '\e[38;5;198m'"++++ Install Argocd using kubectl"
echo -e '\e[38;5;198m'"++++ "
sudo --preserve-env=PATH -u vagrant kubectl apply -n argocd -f https://raw.githubusercontent.com/argoproj/argo-cd/stable/manifests/install.yaml

attempts=0
max_attempts=20
while ! ( sudo --preserve-env=PATH -u vagrant kubectl get pods --namespace argocd | grep argocd-server | tr -s " " | cut -d " " -f3 | grep Running ) && (( $attempts < $max_attempts )); do
  attempts=$((attempts+1))
  sleep 60;
  echo -e '\e[38;5;198m'"++++ "
  echo -e '\e[38;5;198m'"++++ Waiting for Argocd Server to become available, (${attempts}/${max_attempts}) sleep 60s"
  echo -e '\e[38;5;198m'"++++ "
  sudo --preserve-env=PATH -u vagrant kubectl get po,svc --namespace argocd
  sudo --preserve-env=PATH -u vagrant kubectl get events | grep -e Memory -e OOM
done

echo -e '\e[38;5;198m'"++++ "
echo -e '\e[38;5;198m'"++++ Change the argocd-server service type to NodePort"
echo -e '\e[38;5;198m'"++++ "
sudo --preserve-env=PATH -u vagrant kubectl patch svc argocd-server -n argocd -p '{"spec": {"type": "NodePort"}}'

echo -e '\e[38;5;198m'"++++ "
echo -e '\e[38;5;198m'"++++ Get argocd-initial-admin-secret"
echo -e '\e[38;5;198m'"++++ "
export ARGOCD_PASSWORD=$(sudo --preserve-env=PATH -u vagrant kubectl -n argocd get secret argocd-initial-admin-secret -o jsonpath='{.data.password}' | base64 -d)
echo -e '\e[38;5;198m'"++++ Argocd Admin Password: $ARGOCD_PASSWORD"

echo -e '\e[38;5;198m'"++++ "
echo -e '\e[38;5;198m'"++++ kubectl port-forward -n argocd service/argocd-server 18043:80 --address=\"0.0.0.0\""
echo -e '\e[38;5;198m'"++++ "
attempts=0
max_attempts=20
while ! ( sudo netstat -nlp | grep "0.0.0.0:18043" ) && (( $attempts < $max_attempts )); do
  attempts=$((attempts+1))
  sleep 60;
  echo -e '\e[38;5;198m'"++++ "
  echo -e '\e[38;5;198m'"++++ kubectl port-forward -n argocd service/argocd-server 18043:80 --address=\"0.0.0.0\", (${attempts}/${max_attempts}) sleep 60s"
  echo -e '\e[38;5;198m'"++++ "
  sudo --preserve-env=PATH -u vagrant kubectl port-forward -n argocd service/argocd-server 18043:80 --address="0.0.0.0" > /dev/null 2>&1 &
done

echo -e '\e[38;5;198m'"++++ "
echo -e '\e[38;5;198m'"++++ Access Argocd"
echo -e '\e[38;5;198m'"++++ "
echo -e '\e[38;5;198m'"++++ Argocd Server started at http://localhost:18043"
echo -e '\e[38;5;198m'"++++ Login with admin:$ARGOCD_PASSWORD"
echo -e '\e[38;5;198m'"++++ Argocd Documentation http://localhost:3333/#/argocd/README?id=argocd"

# TODO: read token and test login
# boundary authenticate password -login-name=admin -password password -auth-method-id=ampw_1234567890 -addr=http://127.0.0.1:19200
Copy to clipboardErrorCopied
